HT-380 Lorry Refrigeration Unit with Parallel Flow Condenser and R404a Refrigerant for 14m³ Vans

Name: HT380 Lorry Refrigeration Unit with Parallel Flow Condenser and R404a Refrigerant for 14m Vans
Brand: YINHUASHENG
Price: 1 USD

Quality HT-380 Lorry Refrigeration Unit with Parallel Flow Condenser and R404a Refrigerant for 14m³ Vans for sale

Brand Name : YINHUASHENG

Model Number : HT-380

Certification : CE/ISO

Place of Origin : CHINA

MOQ : 1PCS

Price : negotiation

Payment Terms : L/C,T/T

Supply Ability : 1000

Delivery Time : 20

Packaging Details : WOODEN CASE/CARTOON

Applicable Temperature : -25℃ ~ +25℃

Box Volume : ≤14m³

Cooling Capacity : 0℃ 3510 W -18℃ 1970 W

Compressor Model : 5H14 CC 138 CC

Refrigerant Type : R404a

Refrigerant Charge : 1.3KG

Contact Now

HT-380 Lorry Refrigeration Unit with Parallel Flow Condenser, Dayin Compressor, and R404a Refrigerant for 14m³ Vans

Product Overview

The HT-380 Lorry Refrigeration Unit is an ideal solution for refrigerated trucks, designed for maximum performance and reliability. Featuring a white finish and 220V/50Hz voltage specification, this unit combines advanced engineering with efficient cooling technology. The evaporator coil is optimized for maximum efficiency, while the R404a refrigerant ensures reliable operation and peak cooling performance.

Technical Specifications

Parameter	Specification
Unit Model	HT-380
Applicable Temperature	-25℃ ~ +25℃
Box Volume	≤14m³
Cooling Capacity	0℃ 3510 W -18℃ 1970 W
Compressor	Model 5H14 CC 138 CC Lubricating Oil PAG 68
Evaporator	Material: Inner grooved copper tube Number of Fans: 2 PCS
Condenser	Material: Parallel flow condenser Number of Fans: 2 PCS
Refrigerant	R404a
Refrigerant Charge	1.3KG
Box Temperature Adjustment	Electronic digital display
Safety Protection	High and low pressure switch
Defrosting	Hot gas defrost automatically
Weight & Dimensions	Evaporator Weight: 17 KG Condenser Weight: 26 KG Evaporator Dimensions: 1010×580×210 mm Condenser Dimensions: 1040×470×310 mm
Drive Model	Non-independent engine driven

Installation Pictures
